Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Min.dur. trip cmd. 2
021 004
0.25 0.10 10.00 s
[spacer]
Setting for the minimum duration of trip command 2.
[spacer]
MAIN: Min.dur. trip cmd. 3
021 032
0.25 0.10 10.00 s
[spacer]
Setting for the minimum duration of trip command 3.
[spacer]
MAIN: Min.dur. trip cmd. 4
021 033
0.25 0.10 10.00 s
[spacer]
Setting for the minimum duration of trip command 4.
[spacer]
MAIN: Latching trip cmd. 1
021 023
0: No Fig. 3-55, (p. 3-81)
[spacer]
Specification as to whether trip command 1 should latch.
[spacer]
MAIN: Latching trip cmd. 2
021 024
0: No
[spacer]
Specification as to whether trip command 2 should latch.
[spacer]
MAIN: Latching trip cmd. 3
021 025
0: No
[spacer]
Specification as to whether trip command 3 should latch.
[spacer]
MAIN: Latching trip cmd. 4
021 026
0: No
[spacer]
Specification as to whether trip command 4 should latch.
[spacer]
MAIN: Fct. assign. fault
021 031
060 000: MAIN: Without function Fig. 3-52, (p. 3-79)
[spacer]
Selection of the signals to be signaled as Blocked/Faulty in addition to the
messages that always result in the message Blocked/Faulty.
P631
7 Settings
7-76 P631/EN M/R-11-C // P631-310-650
