Micom P631 - Page 375

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Fct.assign. block. 1
021 021
060 000: MAIN: Without function Fig. 3-50, (p. 3-77)
[spacer]
Assignment of functions that will be blocked simultaneously when blocking
input 1 (MAIN: Blocking 1 EXT) is activated.
[spacer]
MAIN: Fct.assign. block. 2
021 022
060 000: MAIN: Without function Fig. 3-50, (p. 3-77)
[spacer]
Assignment of functions that will be blocked simultaneously when blocking
input 2 (MAIN: Blocking 2 EXT) is activated.
[spacer]
MAIN: Fct.assign. block. 3
021 048
060 000: MAIN: Without function Fig. 3-50, (p. 3-77)
[spacer]
Assignment of functions to be blocked together if blocking input 3
(MAIN: Blocking 3 EXT) is activated.
[spacer]
MAIN: Fct.assign. block. 4
021 049
060 000: MAIN: Without function Fig. 3-50, (p. 3-77)
[spacer]
Assignment of functions to be blocked together if blocking input 4
(MAIN: Blocking 4 EXT) is activated.
[spacer]
MAIN: Trip cmd.block. USER
021 012
0: No Fig. 3-55, (p. 3-81)
[spacer]
Blocking the trip commands from the local control panel.
[spacer]
MAIN: Fct.assig.trip cmd.1
021 001
060 000: MAIN: Without function Fig. 3-55, (p. 3-81)
[spacer]
Assignment of signals that trigger trip command 1.
[spacer]
MAIN: Fct.assig.trip cmd.2
021 002
060 000: MAIN: Without function
[spacer]
Assignment of the signals that trigger trip command 2.
[spacer]
MAIN: Fct.assig.trip cmd.3
021 046
060 000: MAIN: Without function
[spacer]
Assignment of signals that trigger trip command 3.
[spacer]
MAIN: Fct.assig.trip cmd.4
021 047
060 000: MAIN: Without function
[spacer]
Assignment of signals that trigger trip command 4.
[spacer]
MAIN: Min.dur. trip cmd. 1
021 003
0.25 0.10 10.00 s Fig. 3-55, (p. 3-81)
[spacer]
Setting for the minimum duration of trip command 1.
7 Settings
P631
P631/EN M/R-11-C // P631-310-650 7-75
