Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Conn.meas.circ. IP,b
010 150
1: Standard Fig. 3-41, (p. 3-64)
[spacer]
Instead of accounting for connection reversal applied to one end in the settings
for DIFF: Vec.gr. ends a-b PSx, it is possible to account for it in the
settings for connection of the measuring circuits. The connection of the phase
current circuits, ends a and b, is set here as Standard if in accordance with the
connection scheme shown in Chapter “Installation and Connection”, else as
Opposite.
[spacer]
MAIN: Meas. value rel. IP
011 030
0.00 0.00 0.20 Inom Fig. 3-44, (p. 3-70)
[spacer]
Setting for the minimum current that must be exceeded so that measured
operating values of the phase currents and, if applicable, derived currents are
displayed.
[spacer]
MAIN: Meas.value rel. Ineg
011 048
0.000 0.000 0.200 Inom
[spacer]
MAIN: Meas.value rel. Ipos
011 058
0.000 0.000 0.200 Inom
[spacer]
Setting for a minimum current that must be exceeded in order for the P631 to
display the negative-sequence (positive-sequence) current as measured
operating data.
[spacer]
MAIN: Meas. value rel. IN
011 031
0.000 0.000 0.200 Inom Fig. 3-45, (p. 3-71)
[spacer]
Setting for the minimum current that must be exceeded so that the measured
operating value of the residual current is displayed.
[spacer]
MAIN: Settl. t. IP,max,del
010 113
15.0 0.1 60.0 min Fig. 3-43, (p. 3-69)
Fig. 3-44, (p. 3-70)
[spacer]
Setting for the time after which the delayed maximum current display shall
reach 95% of the maximum current I
P,max
.
[spacer]
MAIN: Fct.assign. reset 1
005 248
060 000: MAIN: Without function Fig. 3-59, (p. 3-85)
[spacer]
Assigning specific memories and counters which are to be reset jointly if
MAIN: Group reset 1 USER is enabled.
[spacer]
MAIN: Fct.assign. reset 2
005 249
060 000: MAIN: Without function Fig. 3-59, (p. 3-85)
[spacer]
Assigning specific memories and counters which are to be reset jointly if
MAIN: Group reset 2 USER is enabled.
P631
7 Settings
7-74 P631/EN M/R-11-C // P631-310-650
