Parameter Address
Default Min Max Unit Logic Diagram
Programmable Logic
LOGIC: General enable USER
031 099
0: No Fig. 3-141, (p. 3-174)
[spacer]
Enable/disable the logic function.
[spacer]
LOGIC: Set 1 USER
034 030
0: No Fig. 3-140, (p. 3-173)
[spacer]
LOGIC: Set 2 USER
034 031
0: No
[spacer]
LOGIC: Set 3 USER
034 032
0: No
[spacer]
LOGIC: Set 4 USER
034 033
0: No
[spacer]
LOGIC: Set 5 USER
034 034
0: No
[spacer]
LOGIC: Set 6 USER
034 035
0: No
[spacer]
LOGIC: Set 7 USER
034 036
0: No
[spacer]
LOGIC: Set 8 USER
034 037
0: No
[spacer]
These settings define the static input conditions for the logic function.
[spacer]
LOGIC: Fct.assignm. outp. 1
030 000
060 000: MAIN: Without function Fig. 3-141, (p. 3-174)
[spacer]
LOGIC: Fct.assignm. outp. 2
030 004
060 000: MAIN: Without function s
[spacer]
LOGIC: Fct.assignm. outp. 3
030 008
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp. 4
030 012
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp. 5
030 016
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp. 6
030 020
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp. 7
030 024
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp. 8
030 028
060 000: MAIN: Without function
P631
7 Settings
7-90 P631/EN M/R-11-C // P631-310-650
