Micom P631 - Page 402

Parameter Address
Default Min Max Unit Logic Diagram
Programmable Logic
LOG_2: General enable USER
011 137
0: No Fig. 3-142, (p. 3-175)
[spacer]
Enable/disable the function group LOG_2 (Programmable Logic 2).
[spacer]
LOG_2: Fct.assignm. outp. 1
050 000
060 000: MAIN: Without function Fig. 3-142, (p. 3-175)
[spacer]
LOG_2: Fct.assignm. outp. 2
050 004
060 000: MAIN: Without function s
[spacer]
LOG_2: Fct.assignm. outp. 3
050 008
060 000: MAIN: Without function
[spacer]
LOG_2: Fct.assignm. outp. 4
050 012
060 000: MAIN: Without function
[spacer]
These settings assign functions to the outputs.
[spacer]
LOG_2: Op. mode t output 1
050 001
0: Without timer stage Fig. 3-142, (p. 3-175)
[spacer]
LOG_2: Op. mode t output 2
050 005
0: Without timer stage
[spacer]
LOG_2: Op. mode t output 3
050 009
0: Without timer stage
[spacer]
LOG_2: Op. mode t output 4
050 013
0: Without timer stage
[spacer]
These settings define the operating modes for the output timer stages.
[spacer]
LOG_2: Time t1 output 1
050 002
0 0 60000 s Fig. 3-142, (p. 3-175)
[spacer]
LOG_2: Time t1 output 2
050 006
0 0 60000 s
[spacer]
LOG_2: Time t1 output 3
050 010
0 0 60000 s
[spacer]
LOG_2: Time t1 output 4
050 014
0 0 60000 s
[spacer]
Settings of timer stage t1 for the respective outputs.
[spacer]
LOG_2: Time t2 output 1
050 003
0 0 60000 s Fig. 3-142, (p. 3-175)
[spacer]
LOG_2: Time t2 output 2
050 007
0 0 60000 s
[spacer]
LOG_2: Time t2 output 3
050 011
0 0 60000 s
