Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DTOC2: tI>> PSx
076 078 077 078 078 078 079 078
0.50 0.00 100.00 s
[spacer]
Setting for operate delay I>>.
[spacer]
DTOC1: tI>>> PSx
076 059 077 059 078 059 079 059
0.50 0.00 100.00 s Fig. 3-92, (p. 3-125)
[spacer]
DTOC2: tI>>> PSx
076 169 077 169 078 169 079 169
0.50 0.00 100.00 s
[spacer]
Setting for the operate delay of the I>>> stage.
[spacer]
DTOC1: Ineg> PSx
076 197 077 197 078 197 079 197
0.25 0.10 8.00 Inom Fig. 3-93, (p. 3-127)
[spacer]
DTOC2: Ineg> PSx
076 207 077 207 078 207 079 207
0.25 0.10 8.00 Inom
[spacer]
Setting for the operate value of the Ineg> stage.
[spacer]
DTOC1: Ineg>> PSx
076 198 077 198 078 198 079 198
Blocked 0.10 8.00 Inom Fig. 3-93, (p. 3-127)
[spacer]
DTOC2: Ineg>> PSx
076 208 077 208 078 208 079 208
Blocked 0.10 8.00 Inom
[spacer]
Setting for the operate value of the Ineg>> stage.
[spacer]
DTOC1: Ineg>>> PSx
076 199 077 199 078 199 079 199
Blocked 0.10 8.00 Inom Fig. 3-93, (p. 3-127)
[spacer]
DTOC2: Ineg>>> PSx
076 209 077 209 078 209 079 209
Blocked 0.10 8.00 Inom
[spacer]
Setting for the operate value of the Ineg>>> stage.
[spacer]
DTOC1: Ineg> dynamic PSx
076 200 077 200 078 200 079 200
1.00 0.10 8.00 Inom Fig. 3-93, (p. 3-127)
[spacer]
DTOC2: Ineg> dynamic PSx
076 210 077 210 078 210 079 210
1.00 0.10 8.00 Inom
[spacer]
Setting for operate value Ineg> dynamic. (Ineg = negative-sequence current)
This operate value is effective only while the timer stage MAIN: Hold time
dyn.param. is elapsing.
[spacer]
DTOC1: Ineg>> dynamic PSx
076 201 077 201 078 201 079 201
1.00 0.10 8.00 Inom Fig. 3-93, (p. 3-127)
