Micom P631 - Page 411

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DTOC2: Ineg>> dynamic PSx
076 211 077 211 078 211 079 211
1.00 0.10 8.00 Inom
[spacer]
Setting for operate value Ineg>> dynamic. (Ineg = negative-sequence current)
This operate value is effective only while the timer stage MAIN: Hold time
dyn.param. is elapsing.
[spacer]
DTOC1: Ineg>>> dynamic PSx
076 202 077 202 078 202 079 202
1.00 0.10 8.00 Inom
[spacer]
DTOC2: Ineg>>> dynamic PSx
076 212 077 212 078 212 079 212
1.00 0.10 8.00 Inom
[spacer]
Setting for operate value Ineg>>> dynamic. (Ineg = negative-sequence current)
This operate value is effective only while the timer stage MAIN: Hold time
dyn.param. is elapsing.
[spacer]
DTOC1: tIneg> PSx
076 203 077 203 078 203 079 203
1.00 0.00 100.00 s Fig. 3-93, (p. 3-127)
[spacer]
DTOC2: tIneg> PSx
076 213 077 213 078 213 079 213
1.00 0.00 100.00 s
[spacer]
Setting for the operate delay of the Ineg> stage.
[spacer]
DTOC1: tIneg>> PSx
076 204 077 204 078 204 079 204
0.50 0.00 100.00 s Fig. 3-93, (p. 3-127)
[spacer]
DTOC2: tIneg>> PSx
076 214 077 214 078 214 079 214
0.50 0.00 100.00 s
[spacer]
Setting for the operate delay of the Ineg>> stage.
[spacer]
DTOC1: tIneg>>> PSx
076 205 077 205 078 205 079 205
0.50 0.00 100.00 s Fig. 3-93, (p. 3-127)
[spacer]
DTOC2: tIneg>>> PSx
076 215 077 215 078 215 079 215
0.50 0.00 100.00 s
[spacer]
Setting for the operate delay of the Ineg>>> stage.
[spacer]
DTOC1: IN> PSx
076 054 077 054 078 054 079 054
0.25 0.10 8.00 Inom Fig. 3-94, (p. 3-129)
[spacer]
DTOC2: IN> PSx
076 164 077 164 078 164 079 164
0.25 0.10 8.00 Inom
[spacer]
Setting for operate value IN>.
[spacer]
DTOC1: IN>> PSx
076 055 077 055 078 055 079 055
Blocked 0.10 8.00 Inom Fig. 3-94, (p. 3-129)
7 Settings
P631
P631/EN M/R-11-C // P631-310-650 7-111
