Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Curr. IP,min,b prim.
005 105
Not measured 0 25000 A
[spacer]
Display of the minimum phase current of end b as a primary quantity.
[spacer]
MAIN: Current IA,a prim.
005 021
Not measured 0 25000 A Fig. 3-44, (p. 3-70)
[spacer]
Display of phase current A, end a, as a primary quantity.
[spacer]
MAIN: Current IB,a prim.
006 021
Not measured 0 25000 A Fig. 3-44, (p. 3-70)
[spacer]
Display of phase current B as a primary quantity, end a.
[spacer]
MAIN: Current IC,a prim.
007 021
Not measured 0 25000 A Fig. 3-44, (p. 3-70)
[spacer]
Display of phase current C as a primary quantity, end a.
[spacer]
MAIN: Current IA,b prim.
005 022
Not measured 0 25000 A
[spacer]
Display of phase current A, end b, as a primary quantity.
[spacer]
MAIN: Current IB,b prim.
006 022
Not measured 0 25000 A
[spacer]
Display of phase current B as a primary quantity, end b.
[spacer]
MAIN: Current IC,b prim.
007 022
Not measured 0 25000 A
[spacer]
Display of phase current C as a primary quantity, end b.
[spacer]
MAIN: Current Ineg a prim.
005 125
Not measured 0 25000 A
[spacer]
MAIN: Current Ineg b prim.
005 129
Not measured 0 25000 A
[spacer]
Display of the negative-sequence current of the respective end as a primary
quantity.
[spacer]
MAIN: Current Ipos a prim.
005 127
Not measured 0 25000 A
[spacer]
MAIN: Current Ipos b prim.
005 134
Not measured 0 25000 A
[spacer]
Display of the positive-sequence current of the respective end as a primary
quantity.
[spacer]
MAIN: Current IN,a prim.
005 121
Not measured 0 25000 A
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-5
