Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Current IN,b prim.
005 122
Not measured 0 25000 A
[spacer]
Display of the residual current calculated by the P631 from the sum of the phase
currents (of the respective end) as a primary quantity.
[spacer]
MAIN: Curr. IP,max,a p.u.
005 111
Not measured 0.000 25.000 Inom Fig. 3-44, (p. 3-70)
[spacer]
MAIN: Curr. IP,max,b p.u.
005 112
Not measured 0.000 25.000 Inom
[spacer]
Display of the maximum phase current (of the respective end), referred to I
nom
.
[spacer]
MAIN: IP,max p.u.,delay a
005 163
Not measured 0.000 25.000 Inom Fig. 3-44, (p. 3-70)
[spacer]
MAIN: IP,max p.u.,delay b
006 163
Not measured 0.000 25.000 Inom
[spacer]
Display of the delayed maximum phase current (of the respective end a)
referred to I
nom
.
[spacer]
MAIN: IP,max p.u.,stored a
005 160
Not measured 0.000 25.000 Inom Fig. 3-44, (p. 3-70)
[spacer]
MAIN: IP,max p.u.,stored b
006 160
Not measured 0.000 25.000 Inom
[spacer]
Display of the delayed stored maximum phase current (for the respective end),
referred to I
nom
.
[spacer]
MAIN: Curr. IP,min,a p.u.
005 107
Not measured 0.000 25.000 Inom Fig. 3-44, (p. 3-70)
[spacer]
MAIN: Curr. IP,min,b p.u.
005 108
Not measured 0.000 25.000 Inom
[spacer]
Display of the minimum phase current (for the respective end) as referred to
I
nom
.
[spacer]
MAIN: Current IA,a p.u.
005 031
Not measured 0.000 25.000 Inom Fig. 3-44, (p. 3-70)
[spacer]
MAIN: Current IB,a p.u.
006 031
Not measured 0.000 25.000 Inom Fig. 3-44, (p. 3-70)
[spacer]
MAIN: Current IC,a p.u.
007 031
Not measured 0.000 25.000 Inom Fig. 3-44, (p. 3-70)
[spacer]
MAIN: Current IA,b p.u.
005 032
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current IB,b p.u.
006 032
Not measured 0.000 25.000 Inom
