Micom P631 - Page 429

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Current IC,b p.u.
007 032
Not measured 0.000 25.000 Inom
[spacer]
Display of phase current A/B/C for the respective end, referred to In.
[spacer]
MAIN: Current Ineg a p.u.
005 126
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ineg b p.u.
005 130
Not measured 0.000 25.000 Inom
[spacer]
Display of the negative-sequence current of the respective end, referred to I
nom
.
[spacer]
MAIN: Current Ipos a p.u.
005 128
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ipos b p.u.
005 135
Not measured 0.000 25.000 Inom
[spacer]
Display of the positive-sequence current (for the respective end), referred to
I
nom
.
[spacer]
MAIN: Current IN,a p.u.
005 141
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current IN,b p.u.
005 142
Not measured 0.000 25.000 Inom
[spacer]
Display of the residual current calculated by the P631 from the sum of the phase
currents of the respective end, referred to I
nom
.
[spacer]
MAIN: Angle phi AB, end a
005 089
Not measured -180.0 180.0 ° Fig. 3-46, (p. 3-72)
[spacer]
Display of the phase shift between A-B, end a.
[spacer]
MAIN: Angle phi BC, end a
006 089
Not measured -180.0 180.0 ° Fig. 3-46, (p. 3-72)
[spacer]
Display of the phase shift between B-C, end a.
[spacer]
MAIN: Angle phi CA, end a
007 089
Not measured -180.0 180.0 ° Fig. 3-46, (p. 3-72)
[spacer]
Display of the phase shift between C-A, end a.
[spacer]
MAIN: Angle phi AB, end b
005 092
Not measured -180.0 180.0 ° Fig. 3-46, (p. 3-72)
[spacer]
Display of the phase shift between A-B, end b.
[spacer]
MAIN: Angle phi BC, end b
006 092
Not measured -180.0 180.0 ° Fig. 3-46, (p. 3-72)
[spacer]
Display of the phase shift between B-C, end b.
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-7
