Micom P631 - Page 430

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Angle phi CA, end b
007 092
Not measured -180.0 180.0 ° Fig. 3-46, (p. 3-72)
[spacer]
Display of the phase shift between C-A, end b.
[spacer]
MAIN: Angle phi A, end a-b
005 090
Not measured -180.0 180.0 ° Fig. 3-47, (p. 3-73)
[spacer]
Display of the phase shift between ends a and b for phase A.
[spacer]
MAIN: Angle phi B, end a-b
006 090
Not measured -180.0 180.0 ° Fig. 3-47, (p. 3-73)
[spacer]
Display of the phase shift between ends a and b for phase B.
[spacer]
MAIN: Angle phi C, end a-b
007 090
Not measured -180.0 180.0 ° Fig. 3-47, (p. 3-73)
[spacer]
Display of the phase shift between ends a and b for phase C.
P631
8 Information and Control Functions
8-8 P631/EN M/R-11-C // P631-310-650
