Parameter Address
Default Min Max Unit Logic Diagram
Differential protec‐
tion
DIFF: Diff. current 1
005 080
Not measured 0.000 40.000 Iref Fig. 3-89, (p. 3-122)
[spacer]
Display of differential current, measuring system 1, referred to I
ref
.
[spacer]
DIFF: Restrain. current 1
005 081
Not measured 0.000 40.000 Iref Fig. 3-89, (p. 3-122)
[spacer]
Display of restraining current, measuring system 1, referred to I
ref
.
[spacer]
DIFF: Diff. current 2
006 080
Not measured 0.000 40.000 Iref Fig. 3-89, (p. 3-122)
[spacer]
Display of differential current, measuring system 2, referred to I
ref
.
[spacer]
DIFF: Restrain. current 2
006 081
Not measured 0.000 40.000 Iref Fig. 3-89, (p. 3-122)
[spacer]
Display of restraining current, measuring system 2, referred to I
ref
.
[spacer]
DIFF: Diff. current 3
007 080
Not measured 0.000 40.000 Iref Fig. 3-89, (p. 3-122)
[spacer]
Display of the differential current for measuring system 1, 2 or 3, respectively,
referred to I
ref
.
[spacer]
DIFF: Restrain. current 3
007 081
Not measured 0.000 40.000 Iref Fig. 3-89, (p. 3-122)
[spacer]
Display of the restraining current for measuring system 1, 2 or 3, respectively,
referred to I
ref
.
