Parameter Address
Default Min Max Unit Logic Diagram
Thermal overload
protection
THRM1: Status replica, TH1
004 150
Not measured -25000 25000 % Fig. 3-114, (p. 3-149)
[spacer]
Display of the buffer content of the thermal overload protection function.
[spacer]
THRM1: Object temperat.,TH1
004 151
Not measured -40 300 °C Fig. 3-114, (p. 3-149)
[spacer]
Display of the temperature of the protected object as determined by function
THRM1.
[spacer]
THRM1: Coolant temp. TH1
004 154
Not measured -40 200 °C Fig. 3-114, (p. 3-149)
[spacer]
Display of the coolant temperature of the protected object.
Depending on the setting at THRM1: Select CTA PSx
or THRM2: Select CTA PSx for coolant temperature acquisition, one of the
following values will be displayed:
●
Setting Default temp. value: Display of the set temperature value.
●
Setting From PT100: Display of the temperature measured by the
resistance thermometer.
●
Setting From 20 mA input: Display of the temperature measured via the
20 mA input.
[spacer]
THRM1: Pre-trip t. left,TH1
004 153
Not measured 0.0 1000.0 min Fig. 3-114, (p. 3-149)
[spacer]
Display of the time remaining before the thermal overload protection function
THRM1 will reach the tripping threshold.
[spacer]
THRM1: Stat. repl., p.u.TH1
004 204
Not measured -25.00 25.00 Fig. 3-114, (p. 3-149)
[spacer]
Display of the buffer content of the thermal overload protection function THRM1
referred to a buffer content of 100%.
[spacer]
THRM1: Object temp. p.u. 1
004 205
Not measured -0.40 3.00 100°C Fig. 3-114, (p. 3-149)
[spacer]
Display of the temperature of the protected object referred to 100°C.
[spacer]
THRM1: Coolant temp. p.u. 1
004 206
Not measured -0.40 2.00 100°C Fig. 3-114, (p. 3-149)
[spacer]
Display of the coolant temperature of the protected object referred to 100°C.
