Parameter Address
Default Min Max Unit Logic Diagram
Binary and analog
output
OUTP: State K 701
150 144
0: Inactive
[spacer]
OUTP: State K 702
150 147
0: Inactive
[spacer]
OUTP: State K 703
150 150
0: Inactive
[spacer]
OUTP: State K 704
150 153
0: Inactive
[spacer]
OUTP: State K 705
150 156
0: Inactive
[spacer]
OUTP: State K 706
150 159
0: Inactive
[spacer]
OUTP: State K 901
150 192
0: Inactive
[spacer]
OUTP: State K 902
150 195
0: Inactive
[spacer]
OUTP: State K 903
150 198
0: Inactive
[spacer]
OUTP: State K 904
150 201
0: Inactive
[spacer]
OUTP: State K 905
150 204
0: Inactive
[spacer]
OUTP: State K 906
150 207
0: Inactive
[spacer]
OUTP: State K 907
150 210
0: Inactive
[spacer]
OUTP: State K 908
150 213
0: Inactive
[spacer]
The state of the output relays is displayed as follows:
●
Without function: No functions are assigned to the output relay.
●
Inactive: The output relay is not energized.
●
Active: The output relay is energized.
This display appears regardless of the operating mode set for the output relay.
