Parameter Address
Default Min Max Unit Logic Diagram
LED indicators
LED: State H 1 green
085 180
1: Active
[spacer]
LED: State H 2 yell.
085 000
0: Inactive
[spacer]
LED: State H 3 yell.
085 003
0: Inactive
[spacer]
LED: State H 4 red
085 006
0: Inactive
[spacer]
LED: State H 5 red
085 009
0: Inactive
[spacer]
LED: State H 6 red
085 012
0: Inactive
[spacer]
LED: State H 7 red
085 015
0: Inactive
[spacer]
LED: State H 8 red
085 018
0: Inactive
[spacer]
LED: State H 9 red
085 021
0: Inactive
[spacer]
LED: State H10 red
085 024
0: Inactive
[spacer]
LED: State H11 red
085 027
0: Inactive
[spacer]
LED: State H12 red
085 030
0: Inactive
[spacer]
LED: State H13 red
085 033
0: Inactive
[spacer]
LED: State H14 red
085 036
0: Inactive
[spacer]
LED: State H15 red
085 039
0: Inactive
[spacer]
LED: State H16 red
085 042
0: Inactive
[spacer]
LED: State H17 red.
085 181
0: Inactive
[spacer]
LED: State H18 red
085 130
0: Inactive
[spacer]
LED: State H19 red
085 133
0: Inactive
