Micom P631 - Page 446

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LED: State H20 red
085 136
0: Inactive
[spacer]
LED: State H21 red
085 139
0: Inactive
[spacer]
LED: State H22 red
085 142
0: Inactive
[spacer]
LED: State H23 red
085 145
0: Inactive
[spacer]
LED: State H 4 green
085 056
0: Inactive
[spacer]
LED: State H 5 green
085 059
0: Inactive
[spacer]
LED: State H 6 green
085 062
0: Inactive
[spacer]
LED: State H 7 green
085 065
0: Inactive
[spacer]
LED: State H 8 green
085 068
0: Inactive
[spacer]
LED: State H 9 green
085 071
0: Inactive
[spacer]
LED: State H10 green
085 074
0: Inactive
[spacer]
LED: State H11 green
085 077
0: Inactive
[spacer]
LED: State H12 green
085 080
0: Inactive
[spacer]
LED: State H13 green
085 083
0: Inactive
[spacer]
LED: State H14 green
085 086
0: Inactive
[spacer]
LED: State H15 green
085 089
0: Inactive
[spacer]
LED: State H16 green
085 092
0: Inactive
[spacer]
LED: State H18 green
085 160
0: Inactive
[spacer]
LED: State H19 green
085 163
0: Inactive
P631
8 Information and Control Functions
8-24 P631/EN M/R-11-C // P631-310-650
