Parameter Address
Default Min Max Unit Logic Diagram
Measured data
output
MEASO: Enabled
037 102
0: No
[spacer]
MEASO: Outp. enabled EXT
036 085
1: Yes
[spacer]
MEASO: Reset output EXT
036 087
0: No
[spacer]
MEASO: Output reset
037 117
0: No Fig. 3-33, (p. 3-48)
[spacer]
MEASO: Valid BCD value
037 050
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 1-digit bit 0 (BCD)
037 051
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 1-digit bit 1 (BCD)
037 052
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 1-digit bit 2 (BCD)
037 053
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 1-digit bit 3 (BCD)
037 054
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 10-digit bit 0 (BCD)
037 055
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 10-digit bit 1 (BCD)
037 056
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 10-digit bit 2 (BCD)
037 057
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 10-digit bit 3 (BCD)
037 058
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 100-dig. bit 0 (BCD)
037 059
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: 100-dig. bit 1 (BCD)
037 060
0: No Fig. 3-34, (p. 3-51)
[spacer]
MEASO: Value A-1 valid
069 014
0: No Fig. 3-36, (p. 3-57)
[spacer]
MEASO: Value A-1 output
037 118
0: No Fig. 3-36, (p. 3-57)
[spacer]
MEASO: Value A-2 valid
069 015
0: No
P631
8 Information and Control Functions
8-40 P631/EN M/R-11-C // P631-310-650
