Parameter Address
Default Min Max Unit Logic Diagram
Definite-time over‐
current protection
DTOC1: Block. tI> EXT
035 120
0: No
[spacer]
DTOC1: Block. tI>> EXT
035 121
0: No
[spacer]
DTOC1: Block. tI>>> EXT
035 122
0: No
[spacer]
DTOC1: Block. tIneg> EXT
036 141
0: No
[spacer]
DTOC1: Block. tIneg>> EXT
036 142
0: No
[spacer]
DTOC1: Block. tIneg>>> EXT
036 143
0: No
[spacer]
DTOC1: Block. tIN> EXT
035 123
0: No
[spacer]
DTOC1: Block. tIN>> EXT
035 124
0: No
[spacer]
DTOC1: Block. tIN>>> EXT
035 125
0: No
[spacer]
DTOC1: Enabled
035 102
0: No Fig. 3-91, (p. 3-124)
[spacer]
DTOC1: General starting
035 128
0: No Fig. 3-95, (p. 3-130)
[spacer]
DTOC1: tGS elapsed
035 129
0: No Fig. 3-95, (p. 3-130)
[spacer]
DTOC1: Starting A
035 104
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Starting B
035 105
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Starting C
035 106
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Starting N
035 107
0: No Fig. 3-94, (p. 3-129)
[spacer]
DTOC1: Starting I>
035 108
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Starting I>>
035 109
0: No Fig. 3-92, (p. 3-125)
