Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DTOC1: Starting I>>>
035 110
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Trip signal tI>
035 114
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Trip signal tI>>
035 115
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Trip signal tI>>>
035 116
0: No Fig. 3-92, (p. 3-125)
[spacer]
DTOC1: Starting Ineg
036 144
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: Starting Ineg>
036 145
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: Starting Ineg>>
036 146
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: Starting Ineg>>>
036 147
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: tIneg> elapsed
036 148
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: tIneg>> elapsed
036 149
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: tIneg>>> elapsed
036 150
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: Trip signal tIneg>
036 151
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: Trip signal tIneg>>
036 152
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: Trip signal tIneg>>>
036 153
0: No Fig. 3-93, (p. 3-127)
[spacer]
DTOC1: Starting IN>
035 111
0: No Fig. 3-94, (p. 3-129)
[spacer]
DTOC1: Starting IN>>
035 112
0: No Fig. 3-94, (p. 3-129)
[spacer]
DTOC1: Starting IN>>>
035 113
0: No Fig. 3-94, (p. 3-129)
[spacer]
DTOC1: tIN> elapsed
035 117
0: No Fig. 3-94, (p. 3-129)
[spacer]
DTOC1: tIN>> elapsed
035 118
0: No Fig. 3-94, (p. 3-129)
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-57
