Parameter Address
Default Min Max Unit Logic Diagram
Overload recording
OL_RC: Reset record. USER
100 003
0: don't execute Fig. 3-69, (p. 3-99)
[spacer]
Reset of the overload memory.
Parameter Address
Default Min Max Unit Logic Diagram
Fault recording
FT_RC: Trigger USER
003 041
0: don't execute Fig. 3-74, (p. 3-105)
[spacer]
Fault recording is enabled from the local control panel for 500 ms.
[spacer]
FT_RC: Reset record. USER
003 006
0: don't execute Fig. 3-75, (p. 3-106)
[spacer]
Reset of the following memories:
LED indicators
Fault memory
Fault counter
Fault data
Recorded fault values
Parameter Address
Default Min Max Unit Logic Diagram
Thermal overload
protection
THRM1: Reset replica USER
039 120
0: don't execute Fig. 3-115, (p. 3-150)
[spacer]
Reset of the thermal replica of the thermal overload protection 1.
Parameter Address
Default Min Max Unit Logic Diagram
Current transformer
supervision
CTS: Reset latch. USER
036 157
0: don't execute Fig. 3-121, (p. 3-155)
P631
8 Information and Control Functions
8-90 P631/EN M/R-11-C // P631-310-650
