Microtronix Access User Guide
15 Product Ordering Information
For information on products, availability, and pricing, please contact: sales@microtronix.com
15.1 Access Gateway Models
The Access Gateway comes in 3 basic hardware platforms: 1000, 4002, and 4002 rackmount. The
following table shows the available interfaces and connector types of each Access Gateway model.
The model designation, mmmm-PSA-RM, has the following interpretation:
mmmm - mother board (1000, 4002)
P – Power input (S = external AC adapter, N = -48VDC)
S – Serial Expansion ports (0 or 4)
A – Application (0=Terminal server, 4=X.25/TCP Gateway, 1=CDR Collection Manager, 2=MWI
Gateway)
RM – 19” 1U rack mount enclosure
Model
RJ45
Ethernet
DB25F
WAN ports
USB host port
interface
DB9M
Serial ports
Power
connector
1000-S0A 1 1 external 0
²
AC adapter
1000-N0A
1 1 external 0
²
-48VDC
4002-S0A 1 2 external or internal
¹
0
²
AC adapter
4002-N0A
1 2 external or internal ¹ 0
²
-48VDC
4002-N0A-RM 1 2 internal
¹
0 -48VDC
4002-N4A-RM
1 2 internal
¹
4
-48VDC
Notes:
1 – A 32GB flash drive may be mounted internally and connected to the internal USB interface.
2 – Serial expansion ports may be added using an external 1, 2, 4, or 8 port USB serial adapter.
All models include the following in the shipped package:
• Access Gateway unit
• 120/240 VAC Power adapter or -48VDC power cable
• Console cable
• Ethernet patch cable
• Documentation CD or USB flash drive
112
