MICROTRONIX Access 1000 - Straight through Cables

Microtronix Access User Guide
11.2.1.1 Straight Through Cables
The following table shows the pin configurations and connector types for each interface type.
DB25M
RS530
DB25F
RS232
DB25F
V.35
M34F
X.21
DB15F
RS449
DB37F
1 1 1 A 1 1
2 2 2 P 2 4
3 3 3 R 4 6
4 4 4 C 7
5 5 5 D 9
6 6 6 E 11
7 7 7 B 8 19,37
8 8 8 F 5 13
9 9 X 13 26
10 10 12 31
11 11 W 35
12 12 AA 23
13 13 27
14 14 S 9 22
15 15 15 Y 5
16 16 T 11 24
17 17 17 V 6 8
19 19 25
20 20 20 H 3 12
22 22 29
23 23 10 30
24 24 24 U 17
Other lengths are available by special order.
94
Part Number Description
811-SC6MF DB25M-DB25F, RS232/V.24 straight through cable, 6 ft
W4025-RS530-DCE-n DB25M-DB25F, RS530 straight through cable, custom length
W4025-V35-DCE-001 DB25M-M34F, V.35 adapter cable, 1 ft
W4025-X21-DCE-001 DB25M-DB15F, X.21 adapter cable, 1 ft
W4025-RS449-DCE-001 DB25M-DB37F, RS449/V.36 adapter cable, 1 ft
