Microtronix Access User Guide
7.4.1 HDLC Interface Status
The HDLC Interface status table provides information for the physical layer. The following table
provides a description of each column.
HDLC Interface Status
Interface Interface(s) that are currently being used for sync server operation.
WAN 0 (hdlc0)
WAN 1 (hdlc1)
Type Interface type.
Clock Clock source.
Rate Clock rate. If an external clock source, will display “unknown”.
Parity Bit encoding. Always NRZ for X.25
Encoding CRC generation/detection. Always CRC-16 for X.25
DSR ON when the interface is enabled.
CD ON when the interface is enabled.
CTS ON when the interface is enabled.
DTR ON indicates the connected device is ready.
OFF indicates the device is not ready or not connected
RTS ON indicates the connected device is ready.
OFF indicates the device is not ready or not connected
57
