Microtronix Access User Guide
2 Installation
The first step that should be taken is to ensure that you have received all the equipment ordered and
that it has not been damaged in transit. If there are any external signs of damage, note them in writing
and contact the transport company to make a claim.
2.1 Packing List
Unless pre-arranged, the following are the lists of the standard items that are packed and shipped with
each model:
2.1.1 Model 1000-S04
Qty Part Number Part Description
1 1000-S04 Access 1000 Gateway unit with -48VDC input connector
1 5883-PSC30U-48 100-240VAC adapter
1 Country-specific AC power cord (NA, EU)
1 [284-MC1MF DB9F-DB25M Console cable
1 811-W6002-06 RJ45 Ethernet patch cable (blue), 6 ft
2.1.2 Model 1000-N04
Qty Part Number Part Description
1 1000-N04 Access 1000 Gateway unit with -48VDC input connector
1 W1000 -48VDC Power cord
1 [284-MC1MF DB9F-DB25M Console cable
1 811-W6002-06 RJ45 Ethernet patch cable (blue), 6 ft
2.1.3 Model 4002-S04
Qty Part Number Part Description
1 4002-S04 Access 4000 Gateway unit with 12VDC input connector
1 589-PS-1213AP 120/240VAC adapter
1 Country-specific AC power cord (NA, EU)
1 [284-MC1MF DB9F-DB25M Console cable
1 811-W6002-06 RJ45 Ethernet patch cable (blue), 6 ft
12
