Microtronix Access User Guide
3.5 Configuring a Terminal Server
To set up a port for asynchronous / serial use, click on the Serial - TCP item in the Terminal Server
section of the main menu to display the configuration form. Configure the interface parameters to
match the attached device, and assign the TCP/IP network parameters to be connected to this
interface. Click on the Status item in the same section of the main menu to check the interface
operation.
Refer to the Terminal Server sections: Serial - TCP item for configuration details, the Status item for
details on the status display, and the Control and Log item for details of that display.
3.6 Configuring a Synchronous Server
To set up a port for synchronous / HDLC use, click on the HDLC – TCP/UDP item in the Synchronous
Server section of the main menu to display the configuration form. Configure the interface parameters
to match the attached device, and assign the TCP/IP network parameters to be connected to this
interface. Click on the Status item in the same section of the main menu to check the interface
operation.
Refer to the Synchronous Server sections: HDLC -TCP/UDP item for configuration details, the Status
item for details on the status display, and the Control and Log item for details of that display.
3.7 Configuring the X.25/TCP Gateway
To set up a port for X.25 use, click on the HDLC Physical Layer, LAPB Link Layer, and X.25 Packet
Layer items in the X.25 WAN section of the main menu to display the configuration form for each layer
of the protocol. Configure the parameters to match the attached device. Refer to the X.25 WAN
section for configuration details: X.25 Packet Layer , LAPB Link Layer, and HDLC Physical Layer.
Click on the Status item of the X.25 WAN section to display the operational status of the X.25
interfaces, and LCI Status to display the operational status of any active logical channels. Refer to the
X.25 Status section for details on the display of X.25 interfaces, and LCI Status for details on the
display of logical channels.
To configure the X.25 to TCP/IP socket interconnections, click on the X.25 to TCP Routes item in the
X.25 Gateway section of the main menu to display the configuration form. Add or modify routing
entries to map incoming X.25 connections to outbound TCP connections.
To configure the TCP to X.25 mapping / routing, click on the TCP to X.25 Routes item in the X.25
Gateway section of the main menu to display the configuration form. Add or edit routing entries to map
incoming TCP connections to outbound X.25 connections.
Click on the Connection Status item of the X.25 Gateway section to display the operational status of
any active X.25–TCP connections.
Refer to the X.25 Gateway sections for configuration details: TCP to X.25 Routes, and X.25 to TCP
Routes, the Connection Status item for details on the status display of X.25-TCP connections, and the
Control and Log item for detail on that display.
3.8 Configuring the SIP/SMDI MWI Gateway
To configure the MWI Gateway, click on the MWI Gateway MWI Gateway items.
21
