Microtronix Access User Guide
Reverse: When checked, this specifies that reverse charging has been selected.
Fast Select: Allows up to 128 byte user data field in the call request and clear indication packets.
Calling Address Extension:
Called Address Extension:
8.2.5.2 Generate outbound TCP/IP connection
Conversion Type: Conversion type that will be used for TCP/IP data transfer: XOT, RAW, MBIT, RAW-
MBIT, RFC1006, Q-MBIT, AEPN, RBP, QRBP, OFTP, LINE, or IAC-ESC. The remote host application
must support this method. Refer to the Conversions and Encapsulations section for details.
IP Address: IP Address of the remote TCP/IP host.
Destination TCP Port: Remote (destination) TCP port number that the remote TCP/IP host will be
listening on.
Local TCP port: Local (source) TCP port number inserted into the connection request to the remote
TCP/IP host. Otherwise, an ephemeral port number is used.
70
