The route setup page provides a route table with all the X.25 to TCP/IP route entries along with a form
for route editing.
8.2.1 Route Table
Upon loading the X.25 to TCP Routes page, the X.25 to TCP Routes table presents the currently
defined X.25 to TCP/IP routes. The higher the route is ranked in the table, the higher the scanning
priority. As entries are added, modified and ranks adjusted, the table will change. These changes are
not finalized until the Save and Apply Changes button has been clicked.
8.2.2 Creating a New Route
1.Under the Identify inbound X.25 connection section of the route edit form, enter the following:
● Select the Local interface which is connected to the peer X.25 host
● The Connection Type, which is either Switched Virtual Circuit (SVC) or Permanent Virtual
Circuit (PVC).
● If an SVC type has been selected, a Called X.25 Address may be entered. If a PVC type
has been selected, a Logical Channel Number in the defined range must be entered.
● A Calling X.25 Address may be specified. This will be inserted into the source or calling
address field of the X.25 call request.
1.Under the Generate outbound TCP/IP connection section of the route edit form, enter the
following:
 The Conversion Type for the TCP/IP connection.
 The IP Address of the remote TCP/IP host.
 The TCP port number that the remote TCP/IP host is listening on.
1. Click the Add Entry button to add the route to the route table. The new route will be added as
the lowest rank.
2. Use the up and down arrows to adjust the ranking of the new route. The lower the number, the
higher the priority the route will take in the scan for a match.
NOTE: routes added to the table do not take effect until the Save and Apply Changes button has been
clicked.
8.2.3 Editing an Existing Route
1. In the X.25 to TCP Routes table, a route may be selected for editing by clicking the radio button
located within the Edit column of the table in the corresponding route row. Once selected, the route
will be loaded into the Route Editing form.
2. Within the form, the route may be modified.
3. In order for the route to be updated in the route table, the Update Entry button must be pressed.
The Add Entry button may also be pressed if a new route is to be created using an existing route
as a template.
