Microtronix Access User Guide
The following table provides the description of each column.
Interface Local interface(s) that are currently being used for synchronous server operation.
Type Interface type.
Clock Clock source.
Rate Clock rate. If an external clock source, will display “unknown”.
Parity Bit encoding.
Encoding CRC generation/detection or none.
DSR ON when the Sync Server application is running
CD When ON, indicates the presence of a TCP connection
CTS ON when a TCP connection is present.
DTR ON indicates the connected device is ready for a connection
RTS ON indicates the connected device is ready for data.
UI framing Indicates whether UI framing is check/generated on the HDLC interface
Encapsulation Indicates the encapsulation (or none) of frame data over the TCP socket
Protocol Indicates the type of IP socket, TCP or UDP
Local IP Local IP address of the socket. No socket if reported as 0.0.0.0
Local port Port number of the local TCP or UDP socket. If the local IP address is 0.0.0.0,
indicates the sync server is listening on that port
Remote IP If not 0.0.0.0, indicates the IP address of a remote client/server.
Remote port If not 0, indicates the TCP or UDP port number of a remote client/server.
