Mindray DP-20 - Network Preset

Setup 11-9
11.5 Network Preset
◼ For local TCP/IP preset and DICOM preset, please refer to “10.1 DICOM Preset”.
◼ The IStorage screen is as follows:
Name
Description
Service Name
Name of the device, cannot be empty
Port
Port of the device, be same with the PC, cannot be empty.
IP Address
IP address of the PC installed with iStorage software, cannot be
empty
Connect
Press to verify connection with the PC server. On PC server, if the
storage path has not been confirmed, a dialog box will pop up and
guide the user to set it. If the storage path on PC has already been
set, here it displays connection successful after clicking this button.
Add
Click it to add the new service to the service list.
Update
To save the changed parameters.
Delete
Click to delete the selected service in the service list.
Save
Click to save and exit the screen.
◼ Add a network service:
1. Set the network server properties as described above.
2. Click [Add] to add the service to the Service list;
