Mindray DP-20 - Mains on Applied Part Leakage; Patient Auxiliary Current

B-4 Electrical Safety Inspection
◼ LIMITS
For BF applied parts,
⚫ 100μA in Normal Condition.
⚫ 500μA in Single Fault Condition.
B.8 Mains on Applied Part Leakage
The Mains on Applied Part test applies a test voltage, which is 110% of the mains voltage,
through a limiting resistance, to selected applied part terminals. Current measurements are
then taken between the selected applied part and earth. Measurements are taken with the
test voltage (110% of mains) to applied parts in the normal and reverse polarity conditions.
The following outlet conditions apply when performing the Mains on Applied Part test.
⚫ Normal Polarity;
⚫ Reversed Polarity.
◼ LIMITS
⚫ For BF applied parts: 5000 μA.
B.9 Patient Auxiliary Current
Patient Auxiliary currents are measured between any selected Applied Part connector and
the remaining Applied Part connectors. All measurements may have a true RMS only
response.
The following outlet conditions apply when performing the Patient Auxiliary Current test.
⚫ normal polarity (Normal Condition);
⚫ reverse polarity (Normal Condition);
⚫ normal polarity with open neutral (Single Fault Condition);
⚫ reverse polarity with open neutral (Single Fault Condition);
⚫ normal polarity with open earth (Single Fault Condition);
⚫ reverse polarity with open earth (Single Fault Condition).
◼ LIMITS
For BF applied parts,
⚫ 100μA in Normal Condition.
⚫ 500μA in Single Fault Condition.
Note:
Make sure the safety analyzer is authorized comply with requirement of IEC61010-1.
Follow the instructions of the analyzer manufacturer.
