15-6 EMC Guidance and Manufacturer's Declaration
TABLE 4
GUIDANCE AND MINDRAY DECLARATIONELECTROMAGNETIC IMMUNITY
The system is intended for use in the electromagnetic environment specified below. The
customer or the user of system should assure that it is used in such an environment.
IMMUNITY TEST
IEC 60601
TEST LEVEL
COMPLIANCE
LEVEL
ELECTROMAGNETIC
ENVIROMENT
GUIDANCE
Proximity
magnetic fields
IEC 61000-4-39
8 A/m
30 kHz
CW
8 A/m
30 kHz
CW
/
65 A/m
134,2 kHz
Pulse modulation
2,1 kHz
65 A/m
134,2 kHz
Pulse modulation
2,1 kHz
7,5 A/m
13,56 MHz
Pulse modulation
50 kHz
7,5 A/m
13,56 MHz
Pulse modulation
50 kHz
TABLE 5
The system is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of the system can help prevent
electromagnetic interference by maintaining a minimum distance between portable and
mobile RF communications equipment (transmitters) and the system as recommended
below, according to the maximum output power of the communications equipment. Portable
and mobile radio communications equipment (e.g. two-way radio, cellular/ cordless
telephones and similar equipment) should be used no closer to any part of this system,
including cables, than determined according to the following method:
Test
frequency
(MHz)
Band(MHz)
Service
Modulation
Maximum
power (W)
Distance
(m)
Immunity test
level (V/m)
385
380 - 390
TETRA 400
Pulse
modulation
18Hz
1.8
0.3
27
450
430 -470
GMRS 460
FRS 460
FM ±5 kHz
deviation 1 kHz
sine
2
0.3
28
710
704 - 787
LTE Band
13,17
Pulse
modulation
217 Hz
0.2
0.3
9
745
