2-10 System Overview
No.
Name
Description
Function
7.
iStation
/
Press to enter or exit the patient information
management system.
8.
F1~F4
User-defined key
You can assign a function to the key.
9.
Biopsy
/
Press to show or hide the biopsy guide line.
10.
Setup
Setting
To open/close the Setup menu.
11.
Del
/
Press to delete the comment, etc.
12.
/
Alphanumeric keys
Same as on PC
13.
Quad
Quad-split screen
Non-Quad mode: enter Quad mode;
Quad mode: switch between windows.
14.
Dual
Dual-split screen
Non-Dual mode: enter Dual mode;
Dual mode: switch between windows.
15.
Comment
/
Press to enter/ exit the character comment
status.
16.
Cine
Cine Review
Press to enter/ exit the Cine Review status.
17.
/
Direction keys
To adjust monitor brightness or contrast when
pressing with <Fn> key.
18.
Menu
/
Press to display or hide a mode-specific
parameter menu.
19.
TGC
/
TGC slider, to adjust the depth gain.
20.
Patient
Patient Information
To open/ exit patient information screen
21.
Body Mark
/
To enter/ exit the Body Mark status.
22.
Probe
Probe switch
Press to switch Probe and Exam Type
23.
Arrow
/
Press to enter or exit the arrow comment status.
24.
End Exam
/
Press to end an exam.
25.
Clear
/
Press to clear the comments or measurement
calipers on the screen.
26.
Cursor
/
Press to show the cursor.
27.
F.pos/
Freq./Rotation
Focus/
Frequency/Rotation
Press: to switch among F.pos, Freq. and
Rotation;
Rotate: to adjust corresponding parameter
28.
P
User-defined key
You can assign a function to the key.
29.
PW
/
Press to enter the PW mode.
30.
M
/
Press to enter the M mode.
31.
B
/
Press to enter the B mode.
32.
Measure
/
Press to enter/exit application measurement
33.
Update
/
Measurement status: press to switch between
the fixed and active end of the caliper;
Switching key: Press to change the currently
active window.
34.
Caliper
/
Press to enter/exit general measurement
35.
Depth
Zoom
/
Press: to switch between Depth and Zoom;
Rotate: to adjust corresponding parameter
