Mindray uMEC10 User Manual

9-6
The priority of RR source is (from high to low): CO
2
measurement and impedance respiration
measurement.
The [RR Source] settings of Resp and CO
2
are linked.
The RR source options and description are shown in the table below.
Option Description
Auto RR source is automatically selected according to the priority.
CO
2
RR source is from CO
2
measurement.
ECG RR source is from impedance respiration measurement.
9.10 Setting Alarm Properties
Select [Alarm Setup >>] from the [Resp Setup] menu. In the popup menu, you can set
alarm properties for this parameter.
9.11 Switching Resp Measurement On/Off
To switch Resp measurement on, select [Imped. Resp Measure. ON] from the [Resp Setup]
menu. To switch Resp measurement off, select [Imped. Resp Measure. OFF] from the
[Resp Setup] menu and then select [Yes ] from the popup dialog box. Then, a line is
displayed in the waveform area and no numeric but [Measurement OFF] message is
displayed in the parameter area.

Mindray uMEC10 Specifications

General

Resolution	800 x 600
ECG	3/5-lead ECG
EtCO2	Optional
Battery	Rechargeable lithium-ion
Battery Life	4 hours
Dimensions	110 mm
Alarm	Audible and visual alarms
Power Supply	AC 100-240V, 50/60Hz
Agent	No
O2	No
