Mindray uMEC10 User Manual

6-2
 You can switch on or off the connected parameter modules in the [Parameters Switch]
window. If a parameter module is switched off, parameter values and waveforms will
not display on the screen.
6.2 Viewing Minitrends
6.2.1 Having a Split-Screen View of Minitrends
You can split the normal screen so that one part of the screen, on the left hand side,
continuously shows graphic minitrends beside waveforms as shown in the figure below.
To have a split-screen view of minitrends, you can:
 Select [Minitrends] QuickKey, or
 Select [Screens] QuickKey[Choose Screen][Minitrends Screen]
, or
 Select [Main Menu][Screen Setup >>][Screen Layout >>][Choose
Screen][Minitrends Screen]
.
Minitrend View

Mindray uMEC10 Specifications

General

Resolution	800 x 600
ECG	3/5-lead ECG
EtCO2	Optional
Battery	Rechargeable lithium-ion
Battery Life	4 hours
Dimensions	110 mm
Alarm	Audible and visual alarms
Power Supply	AC 100-240V, 50/60Hz
Agent	No
O2	No
