18-2
In this review window:
 Select [Trend Group] and you can select a trend group for viewing in the popup menu.
If [Custom 1] or [Custom 2] is selected, you can further select [Define Trend Group].
Then you can select the parameters for viewing in the popup menu.
 You can set the time length of the review window by selecting [Zoom].
 You can set the number of waves displayed in one page by selecting [Waves].
 To browse the graphic trends, you can either:
 Select
or beside [Scroll] to move the cursor one step to the left or right to
navigate through the graphic trends, or
 Select
or to move the cursor one page to the left or right to navigate
through the graphic trends.
A time indicating your current position is displayed above the parameter area. Numeric
measurement values corresponding to the cursor location change as the cursor is moved.
The measurement value that triggered high level alarm has red background. The one that
triggered medium/low level alarm has yellow background.
 By selecting
or beside [Event], you can position the cursor to different event
time.
 By selecting the [Record] button, you can print out the currently displayed graphic
trends by the recorder.
 By selecting the [Print] button, you can set and print out the graphic trends report by the
printer. For how to set the graphic trends report, please refer to chapter 21 Printing.
