Mindray uMEC10 User Manual

A-16
awRR measurement range 0 to 150 rpm
awRR measurement
precision
<60 rpm: ±1 rpm
60 to 150 rpm: ±2 rpm
Apnea time 10 s, 15 s, 20 s, 25 s, 30 s, 35 s, 40 s
Note: The response time is the sum of the rise time and the delay time.
Effect of interference gases on CO
2
measurements
Gas Concentration (%) Quantitive effect*
N
2
O 60
±1 mmHg
Hal 4
Sev 5
Iso 5
Enf 5
O
2
100
Des 15 ±2 mmHg
*: means an extra error should be added in case of gas interference when CO
2
measurements are
performed between 0-40mmHg.
Inaccuracy specifications are affected by the breath rate and I: E change. The end-tidal gas
reading is within specification for breath rate below 15BPM and I: E ratio smaller than 1: 1
relative to the gas readings without breath.
Alarm limit Range Step
EtCO
2
High (low limit + 2) to 99 mmHg
1 mmHg
EtCO
2
Low 1 to (high limit - 2) mmHg
FiCO
2
High 1 to 99 mmHg
awRR High
Adult, pediatric:
Neonate:
(low limit + 2) to 100 rpm
(low limit + 2) to 150 rpm
1 rpm
awRR Low 0 to (high limit - 2) rpm

Mindray uMEC10 Specifications

General

Resolution	800 x 600
ECG	3/5-lead ECG
EtCO2	Optional
Battery	Rechargeable lithium-ion
Battery Life	4 hours
Dimensions	110 mm
Alarm	Audible and visual alarms
Power Supply	AC 100-240V, 50/60Hz
Agent	No
O2	No
