Mindray uMEC10 User Manual

C-10
Item Name
O.M
General User Defaults
C M
UAP, P3-P4 Venous Pressure Scale
Scale˄mmHg˅ * * 0-80
IBP Overlapping Left Scale
Scale (mmHg) * * 0-160
IBP Overlapping Right Scale
Scale (mmHg) * * 0-20
C.1.8 C.O. (for uMEC12/uMEC15)
Item Name
O.M
General User Defaults
C M
Alarm * * On
Alm Lev * * Med
TB High˄ºC˅ * * 39.0
TB Low˄ºC˅ * * 36.0
Comp. Const * * 0.542
Auto TI * * Auto
Manual TI˄ºC˅ * * 2.0
Measuring mode * * Manual
C.1.9 CO
2
(for uMEC12/uMEC15)
Item Name
O.M
General User Defaults
C M
Alarm * * On
Alm Lev * * Med
Operating Mode * * Measure
Sweep * * 6.25 mm/s
Scale˄mmHg˅ * * 50
Apnea Delay * *
Adu, Ped:
Neo:
20
15
RR Source * Auto

Mindray uMEC10 Specifications

General

Resolution	800 x 600
ECG	3/5-lead ECG
EtCO2	Optional
Battery	Rechargeable lithium-ion
Battery Life	4 hours
Dimensions	110 mm
Alarm	Audible and visual alarms
Power Supply	AC 100-240V, 50/60Hz
Agent	No
O2	No
