PRELIMINARY
miniDSP Ltd, Hong Kong / www.minidsp.com / Features and specifications subject to change without prior notice 16
2.4 REMOTE CONTROL
The remote control provided with the processor controls all key runtime functions.
Source
Cycles through the input sources in the indicated order:
SHD: RCA (unbalanced analog), XLR (balanced analog), USB, LAN (Ethernet),
TOSLINK, SPDIF, AES-EBU
SHD Studio: USB, LAN (Ethernet), TOSLINK, SPDIF, AES-EBU
1, 2, 3, 4
Switches to the selected preset. Note that it takes a few seconds for the preset
selection to complete, while the processor loads the new filters from its flash
memory into the DSP.
[Bell]
Enables or disables Dirac Live filtering. Dirac Live filtering will be effective only
on presets for which Dirac Live filters have been loaded.
Vol
Reduce or increase the volume. Each press changes the volume in 0.5 dB.
Holding down a button will accelerate volume change to 3 dB steps.
Mute
Mutes and unmutes audio output.
