PRELIMINARY
miniDSP Ltd, Hong Kong / www.minidsp.com / Features and specifications subject to change without prior notice 74
10 ADDITIONAL INFORMATION
10.1 SPECIFICATIONS
All SHD Series processors
Computer connectivity Driverless USB 2.0 control interface for Windows and Mac OS X
USB audio input XMOS asynchronous USB audio, 44.1 to 192 kHz stereo PCM, USB Audio Class 2
compliant. ASIO driver for Windows, driverless for macOS / OS X.
Digital audio inputs
Digital audio source selectable from IR remote or front panel:
• AES-EBU on Neutrik 3-pin female XLR / Isolated with digital audio transformer
• SPDIF on RCA connector / Isolated with digital audio transformer
• Toslink on Optical connector
The input signal is processed by a high quality onboard Asynchronous Sample Rate
Converter for compatibility with most common sample rates (20-216kHz).
Ethernet audio input Audio streaming with Volumio, up to 192 kHz sample rate
Audio resolution 32-bit input and output resolution, 96 kHz internal sample rate
Audio processing 32-bit floating-point processor. Flexible matrix mixer, Dirac Live®, user-
programmable IIR filtering, individual delays and gains per channel.
Filtering capabilities Dirac Live mixed-phase filtering, implemented with Dirac Live Calibration Tool for
miniDSP (DLCT).
User-programmable IIR filters: high pass and low pass crossover filters up to 48
dB/octave per output channel; ten biquad filters (parametric) EQ per output
channel – peaking, low-shelf, and high-shelf types.
Storage/presets
All output channel settings controllable in real time from software user interface.
4 onboard presets stored in local flash memory.
Infrared remote Basic remote supplied. Also supports “learning remote” capabilities (NEC, Philips,
Sony) for third-party remotes.
