3 SOFTWARE OVERVIEW
SHD Series processors are configured by software running on a PC or Mac. There are two programs: Dirac Live
Calibration Tool (DLCT) and the SHD plugin. If you are interested in using the SHD Series processor for stereo
room correction only, please follow the steps on this page. If you wish to use the full processing features of the
SHD Series, please follow the steps on the next page.
3.1 CONFIGURATION STEPS FOR STEREO ROOM CORRECTION
The steps for configuring the SHD Series processor for stereo Dirac Live® room correction only are summarized
as follows:
1. Connect the SHD Series processor into your system and install
software. See Sections 4 and 5.
2. Run a series of acoustic measurements using the Dirac Live
Calibration Tool for miniDSP program, to capture the acoustic
behavior of your speakers and room. See Section 6.
3. Generate digital room correction filters that will be executed by
the DDRC-88A processor. Up to four filter sets can be
downloaded into the processor for easy real-time recall and
auditioning. See Section 7.
4. Once the digital room correction filters are designed and
downloaded, the computer can be disconnected for normal
listening. Or, use it to stream audio over USB to the SHD
Series processor.
