14 (119) Telephone Access System Installation and Operation Manual Version 3.7
LT-969 Copyright January 2017
Introduction
• Provision for card reader (sold separately) or postal lock (TX3-1000-4U-B
only)
• Provision for TX3-CX-1NP Single Door Control Module, sold separately
(TX3-1000-4U-B only)
TX3-2000-4U-A and TX3-2000-4U-B: Slim-Line Electronic Scrolling
Directory Lobby Control Unit Kit
• 4 Line by 20 LCD character display
• Main controller board for 2000 residents
• PS-4P Transformer
• Slim-line Universal Enclosure complete with Rain Hood and Light
Assembly
• IP capable
• Provision for card reader (sold separately) or postal lock (TX3-2000-4U-B
only)
• Provision for TX3-CX-1NP Single Door Control Module, sold separately
(TX3-2000-4U-B only)
1.3.3 Universal Slim-Line Kit
The Universal Slim-Line series is available as a kit:
TX3-NSL-12K. The TX3-NSL-12K kit consists of:
• TX3-200-4U slim-line entry panel with speaker and microswitch
for postal lock
• 4x20 LCD display
• PS-4P transformer plug
• TX3-NSL-8M Master NSL Relay Cabinet with one PS-4P
transformer plug
• 2012K Twelve Telephone Relay Kit with a 2012 Twelve Telephone
Relay board and a 9106 Cable
• RJ-71C Punch Down Block for outdoor applications
TX3-NSL-12K-A. This is the IP capable version of the TX3-NSL-12K and
comes with the TX3-200-4U-A panel instead of the TX3-200-4U.
The Universal Panel Accessories consist of the following:
Model TX3-UFT. Universal Flush mounting trim for use with TX3-120U, TX3-
200-8U, TX3-1000-8U and TX3-2000-8U. Stainless steel.
Model TX3-USFT. Universal Slim-Line Flush mounting trim for TX3-200-4U.
Stainless steel.
