Mircom TX3 Series - Table 2 Lobby Control Unit SW1 DIP Switch Settings

Lobby Control Unit Setup
Version 3.7 Telephone Access System Installation and Operation Manual 63 (119)
LT-969 Copyright January 2017
Table 2 shows the SW1 DIP switch settings for each Lobby Control Unit.
Note: DIP switch 7 must on ON for Touch Screen units and OFF for non-
Touch Screen units.
Note: For units with an IP Module installed, DIP Switch 8 determines how
the IP address is assigned to the IP Module.
• DIP Switch 8 OFF: The IP address is assigned using a DHCP
server. This is the default factory setting.
• DIP switch 8 ON: The IP address is assigned using the TX3
Configurator software.
Table 2: Lobby Control Unit SW1 DIP Switch Settings
Lobby Control Unit ID # Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6
0 (not allowed as a Lobby
Control Unit ID 0 is used
for PC ID)
OFF OFF OFF OFF OFF OFF
1 ON OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF
5 ON OFF ON OFF OFF OFF
6 OFF ON ON OFF OFF OFF
7ONONONOFFOFFOFF
8 OFF OFF OFF ON OFF OFF
9 ON OFF OFF ON OFF OFF
10 OFF ON OFF ON OFF OFF
11 ON ON OFF ON OFF OFF
12 OFF OFF ON ON OFF OFF
13 ON OFF ON ON OFF OFF
14 OFF ON ON ON OFF OFF
15 ON ON ON ON OFF OFF
16 OFF OFF OFF OFF ON OFF
17 ON OFF OFF OFF ON OFF
18 OFF ON OFF OFF ON OFF
19 ON ON OFF OFF ON OFF
20 OFF OFF ON OFF ON OFF
21 ON OFF ON OFF ON OFF
22 OFF ON ON OFF ON OFF
23 ON ON ON OFF ON OFF
24 OFF OFF OFF ON ON OFF
25 ON OFF OFF ON ON OFF
26 OFF ON OFF ON ON OFF
