Mircom TX3 Series - Figure 7 Reinforcement Bracket with Nuts; Figure 8 Kiosk Base Plate with Bolts; Figure 9 Kiosk Mounting Holes

32 (119) Telephone Access System Installation and Operation Manual Version 3.7
LT-969 Copyright January 2017
Enclosure Installation
Figure 7 Reinforcement Bracket with nuts
5. Remove the remaining 8 bolts that attach the Kiosk to the base plate, as
shown in Figure 8.
Figure 8 Kiosk Base Plate with bolts
The 12 Kiosk mounting holes in the base plate are shown in Figure 9.
Figure 9 Kiosk Mounting Holes
Bolts (x8)
Base Plate
Cutout
Kiosk Mounting Holes (x12)
