Introduction
Version 3.7 Telephone Access System Installation and Operation Manual 17 (119)
LT-969 Copyright January 2017
• Main controller board for 2000 residents
• PS-4P Transformer
• Continental Enclosure
• Designed for indoor applications
• IP capable
1.3.5 Kiosk Free Standing
TX3-2000-8K-A: 8 line Voice Entry panel, Kiosk style mount for 2000 names.
1.4 Lobby Control Unit Accessories
The Lobby Control Unit accessories consist of the following items:
• TX3-UFT Universal series flush trim ring.
• TX3-USFT Slim line Universal Series flush trim ring.
• TX3-UGA Gooseneck mounting adapter designed for use with the
standard Universal Series enclosure for pedestals.
• TX3-USGA Gooseneck mounting adapter designed for use with the TX3-
200-4U Slim Line Universal enclosure pedestals.
• TH-102 Thermostat Heater with one PS-24P Transformer Plug
•CAM-2 TX3 Camera
• TX3-MDM Modem Module
• TX3-GPM Guard Phone Module
• TX3-USB-AD USB to RS-485 Adapter
• TX3-IP IP Module
• TX3-CX-1NP Single Door Control Module, PoE, 12 VDC, 24-48 VDC
1.5 Mounting requirements from the 2010 ADA
Standards for Accessible Design
See http://www.ada.gov/ for more information.
308.2 Forward Reach.
308.2.1 Unobstructed. Where a forward reach is unobstructed, the high forward
reach shall be 48 inches (1220 mm) maximum and the low forward reach shall be
15 inches (380 mm) minimum above the finish floor or ground.
