NSL Relay Cabinet Installation and Wiring
Version 3.7 Telephone Access System Installation and Operation Manual 79 (119)
LT-969 Copyright January 2017
Figure 44. ADSL-100 Filter Module Installation
NSL Controller
MD-923
P4
P1
LINE
T R
PHONE
T R
MODEM
T R
ADSL-100
Back Plane
MD-612
Line to P4 on NSL Controller
Phone to P1 on Back Plane
