4 (119) Telephone Access System Installation and Operation Manual Version 3.7
LT-969 Copyright January 2017
5.3 Wiring the TX3-NSL-8M Main Controller Board 73
5.4 Updating Firmware 90
6 Elevator Restriction Unit Installation and Configuration 91
6.1 Elevator Restriction Cabinet Mechanical Installation 92
6.2 Elevator Restriction Units 94
6.3 Wiring the Elevator Restriction Unit 96
6.4 Elevator Restriction Controller Backplane 99
6.5 2012E Elevator Restriction Relay Card 100
6.6 Elevator Restriction Unit Configuration 101
6.7 Updating Firmware 103
7 Adding Controllers 104
7.1 Adding a Controller 105
8 Appendix 106
8.1 Specifications 107
9 Resident Operating Instructions 109
9.1 NSL Resident Operating Instructions 110
9.2 ADC Resident Operating Instructions 112
Warranty & Warning Information 113
Special Notices 116
