Version 3.7 Telephone Access System Installation and Operation Manual 7 (119)
LT-969 Copyright January 2017
List of Tables
Table 1 RS-485 Add-on Jumper Settings 60
Table 2 Lobby Control Unit SW1 DIP Switch Settings 63
Table 3 NSL Relay Cabinet Dimensions 70
Table 4 Sample Backplane Relay Addresses 81
Table 5 CA-71A BIX Block Identification Form 85
Table 6 RJ-71C Punch-Down Block Identification Form 88
Table 7 Lobby Control Unit SW2 DIP Switch Settings 101
