Elevator Restriction Unit Installation and Configuration
Version 3.7 Telephone Access System Installation and Operation Manual 93 (119)
LT-969 Copyright January 2017
To mount the Elevator Restriction Unit Cabinet
1. Using the back cover as a template mark the top two mounting hole
locations 6 3/16 inches apart as shown in Figure 49.
2. Place the screws halfway into the wall in the position shown using a
suitable screw.
3. Hang the box onto the two screws.
4. Screw the other two screws at the bottom of the panel.
5. Tighten all four screws into place.
