POWER TRAIN
-
Manual Transaxle
2-17
REVERSE GEAR
L
The 5-R synchronizer sleeve and the reverse idler
idler gear, and into the 1-2 synchronizer sleeve.
gear move rearward and engages with both input
The sleeve turns the synchronizer hub and output
shaft reverse gear and the gear teeth around the
shaft. The output shaft pinion gear turns the
differen-
outside of the l-2 synchronizer sleeve. Input power tial ring gear in the reverse direction. The gear ratio
goes through the input shaft, across the reverse
for reverse is
3.42:1.
Reverse idler gear
\
Input shaft
reverse
/
gear
Reverse gea;
teeth
on outside of
l-2 synchronizer sleeve
0475-066
