Mitsubishi ECLIPSE Technical Information Manual

BODY - Keyless Entry System
4-19
/’
L
L
Code registration switch
V
*-<--
I *T-"s
L3
Receiver
18N0384
Timing Chart
Code
registration
switch
OPERATION IN CODE REGISTRATION MODE
(PROGRAMMING)
When the code registration switch is in the SETI or SETII
position, the receiver enters the registration mode where it
stores the first received secret code in the EEPROM.
Two different secret codes can be stored with the switch in
the SETI and ,SETII positions. Therefore, the user can use
two transmitters.
SET-l
FIX
SET-II
Signal sent from
transmitter A
Signal sent from
transmitter B
Valid
-
Signal received
by receiver
1 ’
SET-I Starts accepting
secret code
to be stored.
Invalid
Valid
Invalid
r--7
r--q
I
I
I I
I I
I
I
I
’ ’ i sE!ll “:‘-; ! /
Secret code is stored in EEPROM when
the switch is changed over from SET-l
or SET-II to FIX.
*EC0574
